3 ton - 3.5ton rough terrain forklift - 4 wheel drive

3 ton - 3.5ton rough terrain forklift - 4 wheel drive

Model NO.: FDR30 - FDR35 -H - 4wd
Price:: USD 12000.00-12000.00 / unit
Delivery: FOB
Minimum order quantity: 1 unit
Supply Ability: 300 unit / Month
Country of Origin: Xiamen

Quantity:

Product Description

Applicable Industries:Building Material Shops
Applicable Industries:Machinery Repair Shops
Applicable Industries:Manufacturing Plant
Applicable Industries:Food & Beverage Factory
Applicable Industries:Farms
Applicable Industries:Construction works
After Warranty Service:Online support
Local Service Location:Brazil
Local Service Location:Peru
Local Service Location:Spain
Local Service Location:Japan
Local Service Location:Argentina
Local Service Location:UAE
Local Service Location:South Africa
Showroom Location:Canada
Showroom Location:Philippines
Showroom Location:Indonesia
Showroom Location:Kenya
Showroom Location:UAE
Condition:New
Place of Origin:CN;FUJ
Power Souce:Diesel Engine
Warranty:1 year
After-sales Service Provided:Free spare parts
Brand Name:LTMG
Max. Lifting Height:6 meter
Min. Lifting Height:0
Fork Length:1220mm
Fork Width:125mm
Overall Dimensions:3046*1605*2205
Certification:CE&ISO9001

Product Show

Product Parameter

1	Model						FDR30T2	FDR35T2
2	Power Type						Diesel	Diesel
3	Rated Capacity					kg	3000	3500
4	Load Centre					mm	600	600
5	Lift Height					mm	3000	3000
6	Fork Size			L×W×T	mm	1220×125×45	1220×125×50
7	Mast Tilt Angle			F/R	Deg	8°/10°	8°/10°
8	Front Overhang (Wheel center to fork face)					mm	591	606
9	Ground Clearance（Bottom of mast）					mm	230	230
10	Overall Dimension			Length to face of fork(Without fork)	mm	3046	3116
11					Overall Width	mm	1605	1605
12					Mast Lowered Height	mm	2205	2240
13					Mast Extended Height(With backrest)	mm	4200	4200
14					Overhead Guard Height	mm	2150	2150
15	Turning Radius (outside)					mm	2750	2810
16	Min. insecting aisle					mm	2900	2960
17	Speed			Travel (Full load)	km/h	18	18
18	Speed				Lifting (Full load)	mm/s	430	400
19	Max.Gradeability (No load/Full load)					%	20	20
20	Tire			Front	mm	14-17.5-14PR	14-17.5-14PR
21	Tire				Rear	mm	27×10-12-12PR	27×10-12-12PR
22	Wheelbase					mm	1835	1835
23	Service weight					kg	4800	5150
24	Battery	Voltage/Capacity			V/Ah	12/80	12/80
25	Engine	Model				4TNE98
26			Manufacture				YANMAR
27			Rated output/r.p.m.			kw	43/2300
28			Rated torque/r.p.m.			N·m	177.6-196.3/1700
29			No.of Cylinder				4
30			Bore×Stroke			mm	98×110
31			Displacement			cc	3318
32			Fuel Tank Capacity			L	60	60
33	Transmission	Type				Hydraulic	Hydraulic
34	Transmission		Stage	FWD/RVS		1/1	1/1
35	Operating Pressure for Attachment					Mpa	18	18

Product Advantage

Standard configuration domestic Xinchai engine,Euro 3 engine and Conmins Engine Optional

Modular design aluminum radiator,quick cool heat

Steel shed to protect lamp in rough condition

High ground clearance
Offer geater maneuverability and keep the machine moving in the roughest of applications

New ergonomic design cabin,comfortable chair,integrated control panel,provide the best working condition for operator

Adjustable side shift to meet more working requirement. and assemble various attachments

Optional

1.Japan engine ISUZU or Mitsubishi,EPA koller engine ,Euro III engine
2.Lifting Height 3m-7m
3.Full-free Duplex or Triplex Mast
4.Side Shift, Solid Tires, Suspension Seat, fork positioner .
5.Driver's Cabin, Customized Color, air-conditioner, etc.
6.Attachments :paper roll clamp,bale clamp ,rotating clamp etc.

LPG&Gasoline Forklift

Packing&Shipping

Company Introduction

Since foundation, LTMG Machinery Group(LTMG) has always kept its professional role in Chinese Material Handling Equipment&Construction Machinery industry. At present, Forklift production base owns 120,000 square meters production base and 15000 units forklifts annual production capacity. with product type and series: 1-40 ton Forklift Trucks(diesel, gas online, LPG, battery),1-20 ton Rough Terrain Forklifts, Electric Pallet Trucks, Side Loader Forklift, Reach Stacker, 1-8 ton wheel loaders,10-40 ton forklift,loaders,(as well as grapple loaders, side loaders.)， wheel excavators and so on .
